Product Specifications
The product includes multiple specifications with diameters of DN15, DN20, DN25, and DN32, and connection types of BSP (British Standard Pipe Thread) and NPT (National Pipe Thread).
The maximum working pressure is 1.0 megapascal (Mpa).
Electrical Parameters
The rated voltage has multiple options, namely direct current 5 volts (DC5V), direct current 12 volts (DC12V), direct current 24 volts (DC24V), and alternating/direct current 9 - 24 volts (AC/DC9 - 24V).
The quiescent current is less than or equal to 500 milliamperes (⩽500mA).
Material Information
The valve body is made of brass.
The actuator is made of engineering plastics, and the actuator torque is 2 newton - meters (N.m).
The gasket seat material is polytetrafluoroethylene (PTFE), and the sealing material is fluoroelastomer (FKM).
Performance Parameters
The switching time is less than or equal to 7 seconds (⩽7S), and the service life can reach 70,000 times.
Environmental and Operating Conditions
The ambient temperature range is from -15°C to 50°C, and the liquid temperature range is from 2°C to 90°C.
There is no manual operation mode, and it has a switch indication.
Multiple wiring methods are provided, such as CR201, CR301, CR303, CR501, CR702, and CR703. The protection level is IP67.
