Choosing Between Sch 40 and Sch 80 PVC Pipes

Sch 80 pipes are stronger due to their thicker walls. They can withstand higher internal pressures. Sch 40 pipes usually have a pressure - rating in the range of 160 - 200 psi (pounds per square inch), depending on the diameter and other factors. In contrast, Sch 80 pipes can handle pressures up to around 400 - 500 psi. This makes Sch 80 pipes a better choice for applications where high pressure is a concern, such as in industrial chemical transfer systems or high - rise building water supply systems where the water pressure at the lower floors can be substantial.

Schedule 40 (Sch 40) PVC pipes have a relatively thinner wall compared to Schedule 80 (Sch 80) pipes. The difference in wall thickness is significant and is designed to meet different strength requirements. For example, a 1 - inch nominal diameter Sch 40 PVC pipe typically has a wall thickness of around 0.133 inches, while a 1 - inch Sch 80 pipe has a wall thickness of about 0.179 inches.

Sch 40 pipes are ideal for most general - purpose residential and light - commercial applications. They are commonly used in cold water supply lines, such as for faucets, showers, and toilets in homes and small businesses. In drainage systems, Sch 40 pipes are also a good choice for handling waste water from sinks, showers, and other fixtures. Sch 80 pipes, on the other hand, are reserved for more demanding applications. They are used in industrial settings to transport chemicals under pressure, in high - pressure water supply systems in high - rises, and in any situation where the pipe needs to have a higher strength and pressure - resistance.

Sch 40 pipes are generally more cost - effective than Sch 80 pipes. The additional material used in Sch 80 pipes to achieve the greater wall thickness makes them more expensive. For example, in a residential plumbing project, the cost of Sch 40 pipes can be 30 - 50% less than that of Sch 80 pipes of the same diameter and length. This cost difference can be a significant factor when choosing between the two, especially in large - scale projects where the cost of materials can have a substantial impact on the overall budget.

Both Sch 40 and Sch 80 pipes have different outer and inner diameters for the same nominal size. This means that the fittings used for each schedule are specific and not interchangeable. When choosing between the two, it's important to ensure that you have the correct fittings that match the schedule of the pipe. Using the wrong fittings can lead to leaks or improper connections. For example, a coupling designed for Sch 40 pipes will not fit properly on a Sch 80 pipe and vice - versa.

Sch 40 pipes are relatively easier to install compared to Sch 80 pipes. Their thinner walls make them lighter and more flexible, which can be an advantage during installation. For example, when bending the pipe slightly to fit around corners or obstacles, Sch 40 pipes are more pliable. They can also be cut more easily using a pipe cutter or a hacksaw.
